TUV Approved XLPO Insulated Tinned Copper Solar PV Cable – 1500V DC, 4mm²-25mm²

TUV Approved XLPO Insulated Tinned Copper Solar PV Cable – 1500V DC, 4mm²-25mm²

Engineered specifically for modern photovoltaic power systems, this TUV certified solar PV cable delivers exceptional electrical performance, environmental resistance, and long-term reliability. Designed to meet the demanding requirements of 1500V DC solar installations, this cable provides a robust solution for solar energy applications worldwide.

✅ Key Features:

• TUV Certification: Independently verified for safety and performance in solar applications
• XLPO Insulation: Cross-linked polyethylene insulation provides superior electrical properties, thermal stability, and environmental resistance
• Tinned Copper Conductors: Premium tinned copper for optimal conductivity, corrosion resistance, and easy soldering
• Voltage Rating: 1500V DC (suitable for modern high-voltage solar systems)
• Temperature Range: -40°C to +90°C (operating), with maximum conductor temperature of 90°C
• Environmental Resistance: Excellent resistance to UV radiation, moisture, ozone, and extreme weather conditions
• Compliance: Meets EN 50618:2014 standard for PV cables
• Flame Retardant: Low smoke zero halogen (LSZH) properties for enhanced safety
• Core Configuration: Single core for DC solar applications
• Color Options: Black (standard) or custom colors available

🔧 Technical Specifications:

• Cable Type: Single Core Solar PV Cable
• Insulation: XLPO (Cross-Linked Polyethylene for Optical, but used for Power)
• Conductor: Tinned Copper (Class 5)
• Voltage Rating: 1500V DC
• Conductor Sizes: 4mm², 6mm², 10mm², 16mm², 25mm²
• Bending Radius: Minimum 6×D (for flexible installation)
• Insulation Resistance: >500 MΩ·km
• Flame Resistance: Meets IEC 60332-1 standard (Low Smoke Zero Halogen)
• Jacket Material: Black XLPO (Cross-Linked Polyethylene)
• Application: Solar PV systems, solar farm installations, rooftop solar, commercial solar projects

🎯 Ideal Applications:

• Large-scale solar farm installations
• Rooftop solar power systems
• Commercial and industrial solar power generation
• Solar energy storage systems
• Off-grid solar power solutions
• Solar-powered water pumping systems
• Solar street lighting installations

Why Choose Our Solar PV Cable?

Unlike standard electrical cables, our TUV approved solar PV cable is specifically designed for the unique requirements of photovoltaic systems. The XLPO insulation provides superior electrical performance and environmental resistance compared to traditional PVC insulation, ensuring reliable operation in harsh outdoor conditions.

The tinned copper conductors offer excellent corrosion resistance and easy soldering, while the 1500V DC rating is essential for modern high-voltage solar systems that maximize energy yield and reduce installation costs.

With TUV certification and compliance with the EN 50618:2014 standard, this cable is the ideal choice for international solar projects requiring high-quality, reliable power transmission. The low smoke zero halogen (LSZH) properties enhance safety in case of fire, meeting the highest international safety standards.

Note: The H1Z2Z2-K designation refers to the international standard for solar PV cables, indicating the specific insulation and construction requirements for photovoltaic applications.

Experience the difference of a cable engineered specifically for solar energy applications. Perfect for solar installers, project developers, and electrical engineers seeking a reliable, high-performance solution for solar power systems worldwide.
