Industrial Building Wiring Insulated Copper Cable for Construction & Power Distribution
Perfect for industrial and commercial construction projects, this insulated copper building wiring cable provides excellent conductivity, strong insulation performance, and long-term reliability. Suitable for hard-wiring, power distribution, and infrastructure installations in African markets.
Available in multiple sizes, insulation options (PVC/XLPE), colors, and customized packaging.
📘 Product Overview
This insulated copper building wiring cable is engineered for industrial, commercial, and residential power wiring applications. Manufactured using high-conductivity copper conductors and durable PVC/XLPE insulation, it ensures excellent electrical performance, safety, and long service life. The cable is ideal for construction projects, distribution networks, lighting circuits, and African infrastructure projects.
📊 Technical Specifications
| Item | Specification |
|---|---|
| Conductor Material | Pure Copper (Solid / Stranded) |
| Insulation Material | PVC / XLPE |
| Rated Voltage | 300/500V, 450/750V, 600/1000V |
| Size Range | 1.0–10mm² (custom sizes available) |
| Color Options | Red, Blue, Yellow, Green/Yellow, Black, Brown |
| Working Temperature | 70°C / 90°C |
| Flame Retardant Level | IEC 60332 (optional) |
| Certification | ISO9001 / CE / RoHS (customizable) |
| Packaging | Coil, roll, wooden drum, carton |
| MOQ | 500–3000 meters |
⭐ Key Features
High-conductivity pure copper conductor
Excellent insulation performance for safe wiring
Suitable for building & industrial hard-wiring
Long-term reliability under continuous operation
Multiple sizes and insulation materials available
Custom colors, printing, and packaging
Designed for global export, especially African markets
🏗 Applications
Industrial building wiring
Commercial building electrical systems
Residential hard-wiring
Lighting and power distribution circuits
Schools, hospitals, factories, and infrastructure projects
Electrical control panels and distribution boards
📦 Packaging & Delivery
Standard coil (100m / 200m / 500m)
Wooden drum for large conductor sizes
Export-ready pallet wrapping
OEM carton printing available
Delivery time: 7–15 days depending on size
Supports FOB / CIF / CFR to global ports
🔒 Certifications & Quality Assurance
ISO9001 Quality Management
CE & RoHS Compliance
IEC Standard Production
SONCAP / KEBS / SABS (optional for African markets)
Factory test reports available upon request
❓ FAQ
Q: Can I get a sample?
A: Yes, small samples are available for testing.
Q: Can the cable be customized?
A: Yes—sizes, insulation, colors, printing, and packaging can all be customized.
Q: Do you ship to African countries?
A: Yes, we export to Nigeria, Ghana, Kenya, Tanzania, South Africa, and more.
| Core Count | 1 Core |
|---|---|
| Conductor Structure | Solid Conductor |
| Conductor Material | |
| Armouring Type | Non-Armoured |
| Sheath Color | Black, Blue, Green, red |
| Fire Performance | Fire Resistant |
| Installation Type | Indoor Installation Cable, Outdoor Installation Cable |
| Insulation Material | PVC |
| Package Type | Coil / Roll, Wooden Pallet |
| Temperature Rating | 70℃, 90℃ |
| Voltage Rating | 0.6/1kV, 450/750V |
| Standards / Certifications | GB / CCC Chinese Standard, IEC Standard, ISO Certification, Nigeria Standard, UL / CSA Certification |
